Turbo Wastegate Repair Kit - BMW B38 - for 11657636784

This wastegate repair kit is for the listed BMW B38 turbocharger references. It repairs the wastegate mechanism; match the original turbocharger and flap design before ordering.

Applications

• BMW - B38 engine; match turbocharger reference.
• BMW 3 Series - match the installed B38 turbocharger and wastegate version.

Turbocharger Selection

Listed turbocharger references: 11657636784, 11652681209, 11658643129 and 11658631700. Inspect wear, damage, play and seating of the original wastegate before choosing a repair.

Installation Requirements

Installation requires turbocharger removal and TIG / argon-arc welding equipment. This is a labour-intensive repair; inspect the complete assembly before replacing the wastegate components.

1. Remove the turbocharger assembly from the engine. Engine removal can improve access; removal without taking the engine out is described as possible with suitable skills. Inspect turbocharger play and catalytic converter condition.
2. Unscrew the vacuum wastegate actuator.
3. Mark the old flap position relative to the turbocharger, then remove the old flap using a grinder.
4. Fit the new flap in the marked position. TIG / argon-arc welding equipment is required; weld the lever to the rod.
5. Refit the vacuum actuator. Replace worn vacuum lines and clean or replace the B38 electromagnetic pressure converters.
6. During installation use new oil feed hoses, cooling-system hoses, seals and gaskets.

Important Before Ordering

Compare the original part number, marking, shape and mounting design before ordering. A model name alone does not confirm the required version.

FAQ

Can the kit be installed without removing the turbo?

No. Turbocharger removal is required.

Is welding required?

Yes. TIG / argon-arc equipment is required to weld the lever to the rod.

Which surrounding parts require attention?

Vacuum lines, pressure converters, oil feed and coolant hoses, seals and gaskets as described in the procedure.

Part Number / PN

11657636784,11652681209,11658643129,11658631700

SKU: KL11657636784.
