AMK Air Suspension Compressor Repair Kit - Range Rover - for LR069691

This repair kit is for the AMK air suspension compressor on the listed Range Rover applications. A piston ring is included; match the installed compressor marking and required repair components before ordering.

Applications

• Range Rover L405 / L494.
• Range Rover (GCAT) - from 2013.
• Range Rover Sport (GCAT) - from 2014.
• Additional brand: Rover - match the original AMK compressor reference.

Repair Components and Selection

A piston ring is included. Original compressor references: LR069691 and LR055953. Additional reference forms: LR108984, LR037070, LR044566, LR047172 and LR056304. Match the complete original AMK compressor marking.

When to Inspect the Air Suspension

• The vehicle rises slowly after starting.
• The compressor runs too often.
• Air suspension faults appear.
• The vehicle sags after parking.
• The compressor overheats or is noisy.
• Pressure builds slowly.

Diagnose the affected compressor and complete air suspension system before repair.

Repair Limits and External Leaks

Check for leaks in the air springs, pipes, reservoir and valve block. Repairing the compressor component will not fix an external system leak that causes frequent compressor starts.

Important Before Ordering

Compare the original part number, marking, shape and mounting design before ordering. A model name alone does not confirm the required version.

FAQ

Is a piston ring included?

Yes.

Can I select by vehicle model alone?

No. Compare the complete original AMK compressor reference and repair design.

Should external leaks be checked?

Yes. Check air springs, pipes, reservoir and valve block; persistent leaks can cause frequent compressor operation.

Part Number / PN

LR069691,LR055953,LR108984,LR037070,LR044566,LR047172,LR056304

SKU: KLLR069691.
